Main Features:

The same European autoclave specifications

1- Capacity: 18 L

2- Instrument containers: 3 trays

3- Water supply system : Reservoirs (3.5L fresh water and 5 liter waste water reservoirs)

4- Divided Display LED Screen as following:

• Bar screen
• Temperature screen
• Main screen

5- Selected button programs:

- 121? program

- 134? program

- B+ program for cotton and gauze and other like materials

6- Sterilization Leakage Test programs:

- Bowie&Dick program

- Leakage program (vacuum test).

7- Dry procedure: vacuum drying

3-programs drying buttons as following:

• 1minute program
• 5minutes program
• 10minutes program

8- Indicator lamps:

• Water indicator lamp
• Ready indicator lamp
• Running indicator lamp

9- Package button programs:

• Wrapped instruments program
• Unwrapped instruments program

10- Start /stop button

11- Sterilizing record: there is a micro-printer connector (printer optional),

recording the whole process of sterilizing

12- Safety Features: Pressure Release Valve and computerized diagnosing

and alarm system

Technical data:

Voltage: 220V±10%

Power: 2300W/1800W10A
