Fully Automatic
8 Preset sterilization programs
Ster. Temp.: 105-134℃
Ster. Time: 4-60 min
Dry time: 1-25min
Vacuum Times: 1-10 times
B&D / Helix / Vacuum testing program
Cleaning Program
Printer & USB Output
Big Stainless Steel Water Tanks
High quality bacteria filter

User Password



Program

121℃ Solid

 121℃ Hollow

 121℃ Porous

 121℃ Solid

 121℃ Hollow

 121℃ Porous

 Vacuum Times

1

3

3

1

3

3

Temp (℃)

121

121

121

134

134

134

Pressure(KPA)

110

110

110

210

210

210

Time(Min.)

20

20

20

4

4

4



Program

Cotton

Prion

User defined





BD/Helix Test





Vacuum Test





Clean

Vacuum Times

3

3

User defined





3

1

3

Temp (℃)

134

134

User defined





134

/

105

Pressure(KPA)

210

210

User defined





210

-80

20

Time(Min.)

4

19

User defined





3.5

15

5

 Warranty:

Two-years warranty for whole machine
Lifetime warranty for chamber
Lifetime maintenance

Standard packing Q'ty (PCS)
Autoclave 1
Power cable 1
Water drain pipe 1
Tray 3
Tray holder 1
Handle for tray holder 1
Fuse 2

Instruction manual 1




The working condition of the autoclave:
*         Relative humidity: ≤80%         Atmospheric pressure: >70kPa;
*         Voltage:230VAC, 50Hz, 2500VA
*         The highest working pressure:  0.21～0.23MPa
*         The highest working temperature: 134～137℃

The requirements of transportation and storage:
*          Environmental temperature range: 5~40℃
*          Relative humidity: ≤80>   No corroding gases

Warning:
*          Please use a 3-hole socket, and ensure the socket has been connected well with the ground. Do not put the autoclave on a place that the power are difficult to be cut off.
*          Do not use power with different voltage with which stated in this manual.
*          Do not touch the plug or socket with wet hands.
*          Do not pull, change, over-bend or twist the wires, and do not put heavy things on the wires.
*          Do not put the autoclave on an unstable table.
*          Do not block the door of autoclave, and cover the ventilation holes and radiation holes.
*          Do not put anything on the top of autoclave.
*          If you find any abnormal smell or sound during operation, please cut off the power immediately and contact your local distributor or us.
