1/10 Cost per patient compared to film

3 seconds to complete entire imaging process

50000+ Exposures with no quality loss

Leading technologies used in nanopix:

AED Technology (Automatic Exposure Detection) -leading technology from chest radiography

• Compatible with almost all DC and AC X-Ray generators
• Digital images comes automatically when your X-Ray is switched on

APS CMOS Technology -from aerospace industry

• High signal-to-noise ratio with maximum details
• Long life and low power consumption

Direct Deposition CSI Technology -from chest radiography

• Low dose radiation for safety
• Less exposure time but higher resolution

Specifications(available in 2 sizes):

	Size 1	Size 2
Detector Technology	APS CMOS	APS CMOS
Scintillator	CsI	CsI
Pixel Matrix	1000*1500	1300*1800
Theoretical Resolution	25lp/mm	25lp/mm
True Resolution	20lp/mm	20lp/mm
Active Area (mm)	20*30	26*36
Mechanical Size(mm)	25.4*36.8*4.4	30.4*41.9*4.4
AD Conversion(bit)	16	16
Data Interface	USB 2.0	USB 2.0
Protection	IP68	IP68
