1/10 Cost per patient compared to film

3 seconds to complete entire imaging process

50000+ Exposures with no quality loss

Leading technologies used in nanopix:

AED Technology (Automatic Exposure Detection) -leading technology from chest radiography

• Compatible with almost all DC and AC X-Ray generators
• Digital images comes automatically when your X-Ray is switched on

APS CMOS Technology -from aerospace industry

• High signal-to-noise ratio with maximum details
• Long life and low power consumption

Direct Deposition CSI Technology -from chest radiography

• Low dose radiation for safety
• Less exposure time but higher resolution

Specifications(available in 2 sizes):



Size 1 - Size 2

Detector Technology

APS CMOS - APS CMOS

Scintillator

CsI - CsI

Pixel Matrix

1000*1500 - 1300*1800

Theoretical Resolution

25lp/mm - 25lp/mm

True Resolution

20lp/mm - 20lp/mm

Active Area (mm)

20*30 - 26*36

Mechanical Size(mm)

25.4*36.8*4.4- 30.4*41.9*4.4

AD Conversion(bit)

16 - 16

Data Interface

USB 2.0 - USB 2.0

Protection

IP68 - IP68

Integrated with Ai
