ENDORAY HF

Technical Data

Class I Electro-medical Apparatus with type-B part applied

Classification

Constant Potential radiographic managed by microprocessor

Head

0.800kW

Rated electrical Power

100 KHz

High frequency technology

0.7 mm (IEC 336)

Focal Spot

6 A

Absorption

6cm

 Of long cone at the end of spacer ?

2mm AL eq.

Total filtration

4-7 mA

Selectable anodic current

60-70 KVp

Selectable voltage to x-ray tube

 0.25 mGy/h a 1 meter from focus 1?

Dispersed radiation

20 mSec-1000 mSec  scala R 10

Exposure time

190-240 V 50/60 Hz

Intermittent operation power supply

1/30 1 sec. Exposure 30 sec. reset max

Intermittent operation

F.F.20 cm

Distance

F 6,3 A T

Fuse

wireless

Deadman logic control
