Specifications:

1- The exclusive thermo switch system gives further safety by blocking Rx emission in the event of a timer break down.

2- Classification: Class I Electro-medical Apparatus with type-B part applied.

3- Head: Self-rectifying single-phase enbloc assembly.

4- Model: AC - KL2 0.8 - 70G.

5- Type 70 Kv.

6- Rated electrical power: 0,430 kW.

7- Supply voltage: 230/240 v (50/60 Hz) single - phase.

8- Absorption 6A.

9- Focal spot: 0,8 mm (IEC 336)

10- Anode current 8 mA.

11- Total filtration: 2mm AL eq.

12- Focus-skin distance 20 cm.

13- ? of beam at end of spacer <6 cm.

14- Dispersed radiation: <0,25 mGy/h at 1 meter from focus.

15- Intermittent operation: 1 s exposure: 60 s reset max.

16- Control logic: WIRELESS Deadman.

17- Maximum apparent resistance of mains power supply: 2 ?.

18- Fuse: Very Fast Acting F 6.3 A

19- Aluminum filter to be interposed between x-ray window and collimator

20- cone :AL, 1 mm (AIP99,9 UNI3567).
